How to Replace Ramp Springs on Trailer

Replacing heavy-duty ramp springs on your trailer, such as 2,000 lb Left & Right Spring Coils, requires careful handling due to the high tension in the springs. Here's a step-by-step guide to replace them safely:

⚠️ Safety First!

• Wear safety glasses and gloves.

• Make sure the trailer is on a flat, stable surface.

• Use wheel chocks to prevent the trailer from moving.

🛠️ Tools & Materials Needed:

• New Left & Right Ramp Springs (2,000 lb capacity)

• Socket wrench and appropriate sockets

• Pliers or vice grips

• Hammer and punch (if needed for removing pins)

• Grease or lubricant

• Jack or support stands (if necessary)

📚 Step 1: Prep the Trailer

• Lower the ramp to the ground to release tension from the springs.

• Inspect the current springs and take note of their placement—left and right springs are wound in opposite directions.

• Clean the area around the hinge and spring housing to make the removal process easier.

🔧 Step 2: Remove the Old Springs

1. Secure the Ramp: Use a jack or support stands to hold the ramp steady while you work.

2. Loosen Retaining Bolts: Using a socket wrench, loosen and remove the bolts securing the springs to the hinge or ramp.

3. Remove the Springs: Carefully slide the springs off the hinge. If they are under tension, use pliers or vice grips to hold the spring while removing it.

🌀 Step 3: Install the New Springs

1. Match the Springs: Verify that the replacement springs are the correct size and tension (left and right orientation matters!).

2. Position the Springs: Place the left spring on the left side and the right spring on the right side of the hinge. Ensure the coils face the correct direction.

   • Left spring: Typically wound counterclockwise.

   • Right spring: Typically wound clockwise.

3. Align the Holes: Align the holes in the spring brackets with the hinge pins.

4. Insert Bolts or Pins: Secure the springs with bolts or pins. Tighten them using the socket wrench but do not overtighten.

🧽 Step 4: Lubricate and Test

• Apply grease or lubricant to the spring coils and hinge points.

• Slowly lift and lower the ramp to ensure smooth operation.

• Check for proper tension and alignment. If the ramp feels too heavy or unbalanced, adjust the tension by repositioning the springs or tightening the bolts.

✅ Step 5: Final Check

• Double-check all bolts and pins for tightness.

• Make sure the springs are properly secured and that the ramp operates smoothly.

⚠️ Pro Tips:

• If the old springs are rusted or difficult to remove, use penetrating oil and allow it to sit for a few minutes.

• Mark the original positions before removing the springs to ensure proper alignment.
